ERMAC SPU-32 Control System
ERMAC SPU-32
Entirely Made in Europe, the ERMAC SPU 32 is our high performance dvLED control system designed for absolute precision in color, detail and stability.
It combines a powerful signal processing engine with advanced color management, automatic calibration and true fiber based connectivity for maximum reliability.
With support for high frame rates, deep bit depth and Pantone validated color accuracy, the ERMAC SPU 32 delivers a consistent and uncompromised image in any environment, from meeting rooms to virtual production volumes and automotive design studios.
It gives users full confidence that their dvLED Display operates exactly as intended, with exceptional uniformity, accuracy and long term performance.
Color Space Engine
The Color Space Engine is a sophisticated algorithm we developed to understand the exact behavior of each specific LED batch and control those LEDs with full precision, creating a color space calibration.
This eliminates the need for any manual color adjustments on the dvLED Display and enables accurate reproduction of Pantone colors at every brightness level and in any environment.
The result is a consistent and reliable color workflow from the designer’s creation all the way to its visualisation on the dvLED Display.
26 Bit internal Processing
Our 26 bit internal processing is the foundation for exceptional detail accuracy on True Performance dvLED Displays.
It provides an extremely fine control of every LED by working with far more internal levels than the incoming signal itself, which preserves subtle color transitions and prevents banding or detail loss.
This becomes especially important at low brightness levels, where many dvLED systems struggle with visible stepping, crushed shadows or unstable colors.
With 26 bit precision every tone, highlight and shadow is represented smoothly and consistently, ensuring that even the most demanding visual content is shown exactly as intended.
Modularity
The ERMAC SPU 32 is built on a fully modular architecture that gives users maximum flexibility in every project.
Its input and output slots can be configured with Display Port, HDMI, SDI, ST2110, Fiber Optic or Ethernet modules, allowing the system to adapt perfectly to any workflow, from design studios to virtual production volumes.
This modularity also ensures long term scalability, since new input standards or output interfaces can be added at any time without replacing the entire processor.
Users benefit from a future proof system that evolves with their requirements and guarantees stable, reliable operation across all applications.
240 Hz Frame Rate Multiview
Our 240 Hz Frame Rate Multiview Technology allows one dvLED Display to show two completely different image streams at the same time while keeping each stream perfectly synchronized.
Each user sees only their own dedicated image through synchronized cameras or active 3D shutter glasses, while spectators looking at the display with the bare eye see a stable and flicker free picture without any visible interference.
In addition to showing two independent images, the system can also present different perspectives of the same virtual object which opens entirely new ways of collaborative interaction.
This makes the technology ideal for virtual production, education and design planning environments where multiple users need to view different information on the same physical display surface without compromising image quality.
ERMAC Control System Parts Overview
